DSB-C100

The D-Link DSB-C100 is a USB Digital Video Camera. It combines state of the art optical technology, hands free Audio Microphone, and complete audio visual software, all at an affordable price which virtually makes it a complete audio visual communications system.

With The D-Link DSB-C100, you can turn your PC into an Internet audiovisual phone. It is the next best thing to being there personally. Get closer to family and friends. The D-Link C-100 delivers 100K resolution. With easy to follow instructions, everything you need to start communicating on your PC is in this box.

Send Video e-mail messages anywhere you send e-mail right now. In fact, there is no additional receiving software required, because you can include a video viewer with each message. It's that simple.

You can even take a snapshot and send it to your friends over the Internet. With the D-Link DSB-C100 you can capture the image and save it in a standard format, so you can edit it and make whatever changes you like. It even lets you build and share a VideoPhone Album.

It has security features too. If you choose the Video Sentry mode, you can actually capture a snapshot of anyone who steps in front of the camera.

The D-Link DSB-C100 is really flexible. In Video-Conference mode you can do one on one chats or full meetings with Group Chatting features.

  • Flicker-Free Still image capture
  • Send Video E-Mail anywhere you send e-mail
  • Add Video Messages to your E-mail
  • Video Conferencing 1 on 1 or with a Group
  • High resolution color (CCD) and CMOS sensor
  • Supports 64 million colors
  • Includes a High Speed USB connection
  • Hands-Free lapel Microphone
  • 30 Seconds of Video Mail at under 500KB file with leading edge compression software
  • Video Sentry security feature for when you are not there

The DSB-Camera allows you to turn your PC into a complete AV system, so go ahead and put a face on your voice in your e-mail messages for truly memorable communications. The D-Link DSB Camera flat out gives you the best value for you dollar and the most messaging for your megabyte.

Standards

  • USB Specification version 1.1
  • OHCI
  • UHCI

Connector

  • One upstream (USB Type A)

Sensor

  • 1/3" CMOS Image Sensor with 100K Pixel (352x288) Resolution

Performance

  • 18 fps @ CIF (352 x 288)
  • 30 fps @ QCIF (176 x 144)

Lens

  • F=1.8/f=6.0mm

Min. Luminance

  • 8 lux

Focus Length

  • 5 mm ~

Gamma

  • 0.45/0.5 Software Selectable

Light Control

  • Automatic Gain Control

Operating Temperature

  • 0C ~ 50C

Storage Temperature

  • -10C ~ 60C

Operating Humidity

  • 10% ~ 90 % non-condensing

Power Requirements

  • Bus Powered - 2.5 W, 0.5 A @ 5 VDC

Compliances

  • CE
  • FCC Class B
  • VCCI

Safety

  • UL
